Computer-controlled scanning of TLC plates for quantitative analysis and method development. Continuous UV-visible wavelength selection supports absorption measurements, with fluorescence available as an option.
Technical Information
| Model | PT-TLC-001 |
|---|
| Wavelength range | 200–850 nm |
|---|
| Measurement modes | Absorption; fluorescence optional |
|---|
| Light sources | Deuterium / tungsten-halogen, automatic switching |
|---|
| Grating density | 1200 lines/mm |
|---|
| Spectral bandwidth | 10 nm |
|---|
| Wavelength accuracy | ±1 nm |
|---|
| Minimum spatial resolution | 25–50 µm |
|---|
Standard configuration
Main instrument including light sources, grating monochromator, moving platform and USB connection; Tstar-3000 TLC workstation software.
Optional configuration
Fluorescence measurement configuration. Computer supply and additional application accessories must be confirmed.
Downloads
Download the language-specific PDF for complete specifications, configuration and application guidance.
Download product PDF
Selection and ordering
Specify plate format, scan wavelength, detection mode and target method. Legacy preset methods require applicability checks; they are not a certification claim.
