Automatic UV-visible scanning with five selectable bandwidths and an eight-inch touchscreen. Supports photometry, quantitative analysis, kinetics and multiwavelength measurement.
Technical Information
| Model | PT-UVS-001 |
|---|
| Optical design | Double beam |
|---|
| Wavelength range | 190–1100 nm |
|---|
| Spectral bandwidth | 0.5 / 1 / 2 / 4 / 5 nm |
|---|
| Wavelength accuracy | ±0.3 nm |
|---|
| Wavelength repeatability | ≤0.1 nm |
|---|
| Monochromator | Czerny–Turner |
|---|
| Focal length | 200 mm |
|---|
Standard configuration
Main instrument, deuterium/tungsten light sources, touchscreen and UVwin8 software package.
Optional configuration
Additional accessories are not specified; confirm sample holders and cuvettes in the quotation.
Downloads
Download the language-specific PDF for complete specifications, configuration and application guidance.
Download product PDF
Selection and ordering
Specify wavelength, bandwidth, sample type and cuvette path length. Confirm software language and computer requirements.
