Stackable refrigerated shaking incubators with independent chamber control, 4–60 °C settings at 25 °C ambient and model-specific chamber counts.
- Independent touch control per chamber
- USB data and alarm records
- Standard observation light and programmable UV
Representative cabinet stack. The pictured flask holders do not depict the required microplate fixtures; select the listed 96-well plate arrangement and chamber count.
Technical Information
| Parameter | Value |
|---|
| Temperature range at 25 °C ambient | 4–60 °C |
| Listed temperature control precision | 0.1 °C |
| Listed speed range | 0–1600 rpm |
| Speed accuracy | ±1 rpm |
| Standard orbit diameter | 3 mm |
| Program capacity | 5 × 30 |
| Electrical supply | AC 220 V ±22 V / 50 Hz |
| Model | Volume per chamber (L) | Independent chambers / levels | Power per level (W) |
|---|
| PT-SHK-040 | 115 | 1 | 800 |
| PT-SHK-061 | 115 | 2 | 800 |
| PT-SHK-062 | 115 | 3 | 800 |
Standard Configuration
Each chamber has independent 7-inch touch control of temperature and shaking, fixed-value or 5-program/30-segment operation, start-temperature or set-temperature timing, scheduling, screen lock, historical curves, alarm records and USB export (up to 150000 records). Pull-out secured platforms, stainless steel interiors with drainage, insulated glass doors, refrigeration with adjustable defrost, observation lighting and programmable UV lamps are standard. Door-open stop, power-restoration memory and temperature/door alarms are listed. UV efficacy is not specified.
Optional Accessories
Humidity control, cultivation lighting and alternative holders are optional. Observation lighting is standard and is distinct from cultivation lighting. Confirm the selected holder set, glassware or plates, electrical service and complete stack delivery. Timer limits and temperature-uniformity data require confirmation for the selected revision.
Downloads
Download the complete datasheet for model specifications and configuration details.
Download PDF - English
Selection / Ordering Information
Specify the PRECETTA model, chamber count, sample vessels and operating conditions. Each load row is an alternative arrangement for the whole selected stack, not a sum of all flask sizes. Per-level power is not total stack power. Confirm utilities, accessories and final configuration.
