Liquid Particle Counter for Medical Device Testing

PT-PC5
Ask a question

PT-PC5 is a touchscreen liquid particle counter for device extracts, filtration assessments and compatible packaging-test samples. Syringe-pump sampling and selectable channel groups support method-specific particle counts.

Key features

  • Touchscreen with documented Chinese input and stored test records
  • Three password-access levels
  • Two custom groups of six channels each

Technical Information

Particle size range1–500 µm
Count range0–9,999,999
Sample volume≥0.1 mL
Sampling volume accuracy±0.3% at 5 mL
Particle concentration range0–10,000/mL
Repeatability (RSD)≤2% (reference particles ≥1000/mL)
Stirring speed0–1500 rpm
Operating temperature0–40 °C
Power supplyAC 220 V ±10% / 50 Hz / ≤90 W
Dimensions420 × 350 × 470 mm

Standard Configuration

Touchscreen instrument with syringe-pump sampling, adjustable glass-propeller stirring and record storage. Confirm the sensor range and complete supply list.

Optional Accessories

Computer connection and data-analysis software require configuration confirmation. Verify sample-contact material compatibility and calibration standards for the selected method.

Applications

Particle contamination and filtration assessments for medical devices and packaging, using a validated sample-extraction and counting procedure.

Selection / Ordering Information

Confirm sample compatibility, configuration, electrical supply and required documentation in the quotation.

Downloads

Download the detailed product datasheet for full specifications and configuration information.

Download PDF - English · PDF

PRECETTA-PT-PC5-en.pdf (PRECETTA-PT-PC5-en.pdf, 441 Kb) [Download]

PRECETTA-PT-PC5-es.pdf (PRECETTA-PT-PC5-es.pdf, 442 Kb) [Download]

PRECETTA-PT-PC5-pt.pdf (PRECETTA-PT-PC5-pt.pdf, 443 Kb) [Download]

PRECETTA-PT-PC5-fr.pdf (PRECETTA-PT-PC5-fr.pdf, 441 Kb) [Download]

PRECETTA-PT-PC5-ar.pdf (PRECETTA-PT-PC5-ar.pdf, 460 Kb) [Download]
